The LH-HPDC-160G energy-saving die casting machine is designed for high-precision aluminum alloy casting. It uses cold chamber die-casting technology to inject molten metal into the mold under high pressure. This ensures the production of fine and high-quality parts.
With a clamping force of 10,000 KN, the machine can handle large and complex molds. It has an opening stroke of 880 mm and supports a wide range of mold thicknesses between 450 mm and 1,150 mm.
With an ejection stroke of 200 mm and an ejection force of 500 KN, it is ideal for efficient removal of castings. The injection position can be adjusted from 0 to -300 mm for better flexibility.
| Parameter | Value |
| Locking Force | 10,000 KN |
| Mold Opening Stroke | 880 mm |
| Mold Thickness Range | 450 - 1,150 mm |
| Tie Bar Distance | 1030 x 1030 mm |
| Ejection Stroke | 200 mm |
| Ejection Force | 500 KN |
| Injection Position | 0, -300 mm |
| Injection Force (Boosted) | 882 KN |
| Injection Stroke | 800 mm |
| Plunger Diameter | 90 - 120 mm |
| Injection Weight (Aluminum) | 17 kg |
| Casting Pressure (Boosted) | 138.6/78 MPa |
| Max Casting Area (40 MPa) | 2,500 cm2 |
| Injection Plunger Penetration | 300 mm |
| Pressure Chamber Flange Diameter | 240 mm |
| Pressure Chamber Flange Height | 20 mm |
| Max Working Pressure | 16 MPa |
| Motor Power | 45 kW |
| Machine Dimensions (L x W x H) | 9.33 x 3.94 m |
| Lifting Reference Weight | 70 T |
| Oil Tank Capacity | 2,000 L |
Advanced PLC control system: simple operation, high stability, ensuring smooth performance.
Reliable hydraulic system: using imported components from Japan YUKEN and Germany REXROTH to ensure system stability.
Energy-saving servo motor: improve energy saving effect while improving injection accuracy and repeatability.
Wide template size range: can accommodate a variety of mold sizes and injection weights to suit different products.
Compact design: optimized to occupy a small space, easy installation and simple maintenance.
High Efficiency: Servo motor drive ensures energy saving while maintaining high performance.
Stable Operation: Advanced PLC control system provides reliable, easy-to-use operation.
Wide Application: Suitable for aluminum and zinc alloy die casting, meeting various production needs.
Precision and Consistency: Enhanced injection accuracy and repeatability, ideal for high-quality parts.
Cost Effectiveness: Energy-saving features reduce operating costs, making it ideal for large-scale production.
Durable Components: The use of imported hydraulic components from YUKEN and REXROTH ensures long-lasting reliability.
Automobile: Produces aluminum and zinc alloy parts for vehicles.
Motorcycle: Manufactures precision parts for motorcycle engines and bodies.
Electrical Appliances: Manufactures durable die-cast parts for household and industrial appliances.
Communications: Ideal for manufacturing parts for communication equipment.
Lighting: Used to produce metal parts for lighting fixtures.
1. Which industries use LH-HPDC-160G energy-saving die casting machine?
LH-HPDC-160G is widely used in automobile, motorcycle, electrical appliance, communication, lighting and other industries for producing high-quality die castings made of aluminum and zinc alloys.
2. What materials can LH-HPDC-160G machine process?
LH-HPDC-160G is designed for die casting aluminum alloy, zinc alloy and other similar materials.
3. What is the clamping force of LH-HPDC-160G?
The clamping force of this machine is 10,000 KN, which ensures a solid and reliable die casting operation.
4. How does LH-HPDC-160G save energy?
The machine is driven by a servo motor to optimize energy efficiency by reducing power consumption while improving injection accuracy and repeatability.
5. What is the injection weight capacity of LH-HPDC-160G?
Aluminium has a shot weight of 17 kg and can produce medium to large parts.
