| LH标准系列参数表(3000T) LH series of standard parameter table (3000 T) | |||
| 项目 ITEMS | 单位 | 参数Specification | |
| 锁模力 Clamping Force | KN | 30000 | 锁模部分 Clamping Unit |
| 锁模行程 Opening stroke | mm | 1500 | |
| 模具厚度（最小—最大）Die thickness(Min--Max) | mm | 800～2000 | |
| 格林柱内距 Space between tie bars | mm | 1650*1650 | |
| 顶出行程 Ejector stroke | mm | 300 | |
| 顶出力 Ejector force | KN | 900 | |
| 压射位置 Injection position（0 as center） | mm | -250，-450 | 压射部分 Injection Unit |
| 压射力(增压）Injection force（intensification) | KN | 2000 | |
| 压射行程 Injection stroke | mm | 1180 | |
| 冲头直径 Plunger diameter | mm | ￠150-￠190 | |
| 射料量(铝) lnjection weight(aluminum) | Kg | 62 | |
| 铸造压力（增压）Casting pressure (intensification) | MPa | 119/73 | |
| 最大铸造面积(40Mpa) Max. casting area(40Mpa) | CM2 | 7500 | |
| 压射冲头推出距离 Injection plunger penetration | mm | 530 | |
| 压射室法兰直径 Diameter of pressure chamber flange | mm | 280 | |
| 压射室法兰凸出定板高度 Height of pressure chamber flange | mm | 30 | |
| 最大工作压力 Max.working pressure | MPa | 16 | 其他 Others |
| 电机功率 Motor power | Kw | 75*2 | |
| 外型尺寸(长*宽*高) Dimensions (L*W*H) | m | 15.3*5.3*5.2 | |
| 机器吊装参考重量 Machine lifting reference weight | T | 200 | |
| 油箱容量Oil tank capacity | L | 5300 | |
1. Precision Plunger Mechanism: The machine's plunger mechanism is designed with high precision to ensure accurate and consistent injection of molten metal. It can control the injection speed and pressure with great accuracy, resulting in high-quality castings with minimal defects.
2. Energy-Saving Design: Our cold chamber die casting machine is designed with energy-saving features in mind. The efficient melting furnace and optimized hydraulic system reduce energy consumption, lowering operating costs and contributing to a more sustainable manufacturing process.
3. Remote Monitoring and Control: The machine can be remotely monitored and controlled, allowing operators to manage the production process from a distance. This feature is especially useful for large-scale production facilities or for situations where remote operation is required. It provides real-time access to the machine's status and allows for quick adjustments to be made.
4. Quick Die Change System: The machine is equipped with a quick die change system that enables fast and easy replacement of dies. This reduces the downtime between production runs and increases the overall productivity of the manufacturing process.
A: The temperature control in our cold chamber die casting machine's melting furnace is highly accurate. The intelligent temperature control system uses advanced sensors and algorithms to maintain the temperature within a very narrow range. This ensures the proper melting and casting of the metal, resulting in consistent quality castings.
A: The lifespan of the die depends on various factors, such as the type of metal being cast, the casting parameters, and the quality of the die itself. With proper maintenance and operation, our cold chamber die casting machine can help extend the lifespan of the die. Regular inspection and maintenance of the die, as well as using high-quality die materials, can contribute to a longer die life.
A: Yes, our cold chamber die casting machine is suitable for both prototyping and mass production. Its flexibility and precision make it an ideal choice for producing small batches of prototypes with high accuracy. At the same time, its high-speed operation and large melting capacity make it capable of handling mass production requirements efficiently.
