| LH标准系列参数表(450T) 非标 LH series of standard parameter table (450 t) | |||
| 项目 ITEMS | 单位 | 参数Specification | |
| 锁模力 Clamping Force | KN | 4500 | 锁模部分 Clamping Unit |
| 锁模行程 Opening stroke | mm | 550 | |
| 模具厚度（最小—最大）Die thickness(Min--Max) | mm | 300～750 | |
| 格林柱内距 Space between tie bars | mm | 660*660 | |
| 顶出行程 Ejector stroke | mm | 130 | |
| 顶出力 Ejector force | KN | 200 | |
| 压射位置 Injection position（0 as center） | mm | 0，-175 | 压射部分 Injection Unit |
| 压射力(增压）Injection force（intensification) | KN | 415 | |
| 压射行程 Injection stroke | mm | 570 | |
| 冲头直径 Plunger diameter | mm | ￠60--￠80 | |
| 射料量(铝) lnjection weight(aluminum) | Kg | 4.8 | |
| 铸造压力（增压）Casting pressure (intensification) | MPa | 148/109/83 | |
| 最大铸造面积(40Mpa) Max. casting area(40Mpa) | CM2 | 1000 | |
| 压射冲头推出距离 Injection plunger penetration | mm | 210 | |
| 压射室法兰直径 Diameter of pressure chamber flange | mm | 110 | |
| 压射室法兰凸出定板高度 Height of pressure chamber flange | mm | 10 | |
| 最大工作压力 Max.working pressure | MPa | 16 | 其他 Others |
| 液冷伺服驱动功率 Power of Liquid cooled servo drive | Kw | 30 | |
| 液冷伺服电机功率 Power of liquid cooled servo motor | Kw | 4 | |
| 外型尺寸(长*宽*高) Dimensions (L*W*H) | m | 7*2*2.87 | |
| 机器吊装参考重量 Machine lifting reference weight | T | 16 | |
| 油箱容量Oil tank capacity | L | 820 | |
