Product features:
· low exhaust temperature and low speed of w-type oil-free compressor
· perfect control system can truly realize unattended and ensure all-weather continuity
work
· frequency conversion adjustment and remote monitoring
· direct connection and water cooling are featured by low noise, small vibration, high reliability and simple operation
· various technical performance indexes, such as efficiency, service life and fuel consumption, have reached the international level
Model | Voiume Flow | Intake pressure | Discharge pressure | Cooling Method | Drving Power | Overall Dimension | Weight |
m3/min | MPa | MPa | kw | mm x mm x mm | T | ||
VW-2/30 | 2 | Atmospheric pressure | 3 | Water cooling | 30kW | 2160×1750×1380 | 2.5 |
VW-2/35 | 2 | Atmospheric pressure | 3.5 | Water cooling | 30kW | 2160×1750×1380 | 2.5 |
VW-2.5/30 | 2.5 | Atmospheric pressure | 3 | Water cooling | 30kW | 2160×1750×1380 | 2.5 |
VW-3/25 | 3 | Atmospheric pressure | 2.5 | Water cooling | 37kW | 2310×1900×1380 | 2.5 |
VW-3/30 | 3 | Atmospheric pressure | 3 | Water cooling | 37kW | 2310×1900×1380 | 2.5 |
VW-3/35 | 3 | Atmospheric pressure | 3.5 | Water cooling | 37kW | 2310×1900×1380 | 2.5 |
VW-3/40 | 3 | Atmospheric pressure | 4 | Water cooling | 37kW | 2310×1900×1380 | 2.5 |
VW-3/60 | 3 | Atmospheric pressure | 6 | Water cooling | 45kW | 2350×1900×1380 | 2.5 |
VW-4/30 | 4 | Atmospheric pressure | 3 | Water cooling | 45kW | 2350×1900×1380 | 3 |
VW-4/40 | 4 | Atmospheric pressure | 4 | Water cooling | 55kW | 2350×1900×1380 | 3 |
VW-4/60 | 4 | Atmospheric pressure | 6 | Water cooling | 55kW | 2350×1900×1380 | 3 |
VW-5/30 | 5 | Atmospheric pressure | 3 | Water cooling | 55kW | 2750×2000×1700 | 3 |
VW-5/40 | 5 | Atmospheric pressure | 4 | Water cooling | 65kW | 2750×2000×1700 | 3 |
VW-6/30 | 6 | Atmospheric pressure | 6 | Water cooling | 75kW | 2750×2000×1800 | 3.5 |
VW-6/35 | 6 | Atmospheric pressure | 3.5 | Water cooling | 75kW | 2750×2000×1800 | 3.5 |
VW-6/40 | 6 | Atmospheric pressure | 4 | Water cooling | 75kW | 2750×2000×1800 | 3.5 |
VW-6/50 | 6 | Atmospheric pressure | 5 | Water cooling | 90kW | 2750×2000×1800 | 3.5 |
VW-7/30 | 7 | Atmospheric pressure | 3 | Water cooling | 75kW | 2860×2000×1800 | 3.5 |
VW-7/40 | 7 | Atmospheric pressure | 4 | Water cooling | 90kW | 2860×2000×1800 | 3.5 |
VW-7.5/60 | 7.5 | Atmospheric pressure | 6 | Water cooling | 110kW | 2860×2000×1800 | 4 |
VW-8/30 | 8 | Atmospheric pressure | 3 | Water cooling | 90kW | 2860×2000×1800 | 4 |
VW-8/40 | 8 | Atmospheric pressure | 4 | Water cooling | 90kW | 2860×2000×1800 | 4 |
VW-8/50 | 8 | Atmospheric pressure | 5 | Water cooling | 110kW | 2860×2000×1800 | 4 |
VW-8/60 | 8 | Atmospheric pressure | 6 | Water cooling | 110kW | 2860×2000×1800 | 4 |
VW-10/25 | 10 | Atmospheric pressure | 2.5 | Water cooling | 110kW | 2860×2000×1800 | 4 |
VW-10/30 | 10 | Atmospheric pressure | 3 | Water cooling | 132kW | 2860×2000×1800 | 4 |
VW-10/40 | 10 | Atmospheric pressure | 4 | Water cooling | 132kW | 2860×2000×1800 | 4 |
